RENOGY ONE Smart Relay
Description
The RENOGY Smart Relay is a Zigbee 3.0 single-channel power relay that supports a max of 16A load. It supports 8 to 30V DC power supply and can be connected to the AC or DC load. You can get multi-scene linkage with other accessories by setting up a unique smart scene via Renogy ONE M1 on your DC Home app.
If you have any questions regarding this product, please submit a case.
Key Features
Stable Wireless Connection with Zigbee 3.0- The Zigbee 3.0 allows long-distance communication with a stable and reliable wireless connection.
- Equipped with premium material that provides complete protection for you and the application environment, the flame-retardant V0 PC shell can also minimize fire hazards.
- Thinner than your palm! The Smart Relay is the perfect size for any small space to fit and saves tremendous installation space.
- Customize a variety of scenarios to meet your personalized needs of smart off-grid life.
Package Includes
|
Smart Relay
1 x
|
3M Adhesive
1 x |
| Specifications | |
|---|---|
| Power Supply: 8-30V DC | Casing Material: PC V0 |
| Load: 250V AC / 30V DC, 16A Max | Applicable Place: Indoor |
| Zigbee: Zigbee 3.0 (IEEE 802.15.4) | Operating Temperature: -4℉~104℉/ -20℃~40℃ |
| Antenna: PCB board with antenna | Operating Humidity: 0%-90%RH, No Condensation |
| Security Mode: WPA/WPA2 | Operating Altitude: Less than 2,000m above sea level |
| Encryption Tpye: AES-128 | Color: White |
| Dimension: 0.79 x 1.57 x 1.73 in / 20 x 40 x 44 mm | Weight: 0.04 lbs / 40 g |
| Certifications | |
| CB | No |
| FCC | Yes |
| CE | No |
| UKCA | No |
| MIC | No |
| ROHS | Yes |
Warranty Information
| Product Warranty |
1 Year |
 |
 |
